Ik begin natuurlijk met de ACCESS SP50 / TRITON BAJA 50:

Steekmaat     VÓÓR=  4X115mm
Steekmaat ACHTER=  4X110mm

De Chinese Bashan:

Steekmaat     VÓÓR=  4X88mm
Steekmaat ACHTER=  4X110mm




Als je een aanvulling op dit steekmatenoverzicht hebt mag je hem altijd doorgeven en dan zet ik hem erbij!


Arctic Cat ATV Steekmaten op type:

Type/Bouwjaar/Velgmaat(V/A) Steekmaat(V/A)

50 2 Stroke Auto 04-05
50 4 Stroke AutoXDVX 06
90 2 Stroke Auto 03-04 8x6 4X110
90 4 Stroke Auto 04-05 8x6 4X110
90 4 Stroke AutoXDVX 06-08 8x6 4X110
250 2x4X4x4 99-07 12x7 4X115
250 2x4 Auto 06-08 10x5, 10x8 4X110
250 DVX 06-08 10x5, 9x9 4X144, 4X110
300 2x4 98-03 12x7 4X115
300 4x4 98-05 12x7 4X115
366 Auto 4x4 FIS 08 12x7 4X115
375 Auto 02 12x7 4X115
400 2x4 98 12x7 4X115
400 2x4 99-01 12x7 4X115
400 2x4, Auto FIS 03 12x7 4X115
400 2x4 Auto FIS 04 12x7 4X115
400 4x4 98 12x7 4X115
400 4x4 99-02 12x7 4X115
400 4x4 03-04 12x7 4X115
400 4x4 MRPXFIS MRP 03-04 12x7 4X115
400 4x4 AutoX Auto VP 03-06 12x7 4X115
400 4x4 Auto FISX Auto FIS LE 04-07 12x7 4X115
400 4x4 Auto FIS MRP 03 12x7 4X115
400i 2x4X4x4 02 12x7 4X115
400 DVX 04-08 10x5, 9x9 4X144, 4X110
454 Bearcat 2x4X4x4 96-98 12x7 4X115
500 2x4 99-01 12x7 4X115
500 4x4 98 12x7 4X115
500 4x4 99 12x7 4X115
500 4x4 00-01 12x7 4X115
500X500i 4X4 02 12x7 4X115
500 4x4 FIS 02-03 12x7 4X115
500 4x4 FIS 04-07 12x7 4X115
500 4x4 FIS 08 12x7 4X115
500 4X4 FIS MRP 03-04 12x7 4X115
500 4x4 Auto 00-02 12x7 4X115
500 4X4 Auto FISXLEXM4 02-06 12x7 4X115
500 4X4 Auto FIS 07 12x7 4X115
500 4x4 Auto FISXM4 08 12x7 4X115
500 4x4 Auto FIS MRP 03-04 12x7 4X115
500 4x4 TBX 02-06 12x7 4X115
500 4x4 TBX 07 12x7 4X115
500 4x4 Auto TRV 03-06 12x7 4X115
500i Auto 4x4 02 12x7 4X115
650 V-Twin 4x4 Auto FISXSEXLE 04-06 12x7 4X115
650 V-Twin 4x4 Auto FIS MRP 04 12x7 4X115
650 H1 Auto FIS LEXSE 05-06 12x7 4X115
650 HI 4x4 Auto TBX 07 12x7 4X115
650 HI 4x4 Auto TRVXLE 05-08 12x7 4X115
650 H1 Prowler 4x4 Auto XTXM4 06-08 12x7 4X115
700 4x4 Auto EFIXLEXH1 SEXM4 07-08 12x7 4X115
700 Diesel 4x4 Auto 07-08 12x7 4X115
700 H1 Prowler 4x4 Auto XTX LE 08 14x6, 14x8 4X115
1000 H2 Thundercat 4x4 Auto SE 08 12x7 4X115




Can-AMXBombardier ATV Steekmaten op type:

Type/Bouwjaar/Velgmaat(V/A) Steekmaat(V/A)

DS50XQuest 02-03
DS50XQuest 04-06
DS90XQuest 02-06
DS90X90FXQuest (2stk) 02-06
Rally 200 07
250 DS 07-09 10x5, 9x8 4X110
330 H.O. 2x4X4x4 Outlander 04-05 12x7 4X137
400 H.O. 2x4 Outlander 04-05 12x7 4X137
400 H.O. 4x4 03-05 12x7 4X137
400 H.O. 4x4 06 12x7 4X137
400 Outlander H.O. Max 4x4 04-06 12x7 4X137
400 H.O. 4x4X4x4 XT Max 04-06 12x7 4X137
Traxter 500 4x4 99-02 12x7 4X110
Traxter 500 4x4 03-05 12x7 4X110
Traxter 500 CVT 05 12x7 4X110
Traxter 500 XT 01-05 12x7 4X110
Traxter 500 XL 01-03 12x7 4X110
Traxter 500 XL 04-05 12x7 4X110
Traxter 500 Max 03-05 12x7 4X110
Quest 500 02-04 12x7 4X110
DS650 00-02 10x5, 9x9 4X144, 4X110
Traxter 650XXT 05 12x7 4X110
Traxter 650 MaxX Max XT 05 12x7 4X110
Quest 650XXT 02-03 12x7 4X110
Quest 650XXT 04 12x7 4X110
Quest Max 650 04 12x7 4X110
Outlander 650 H.O. EFIXXTXMax 06 12x7 4X137
Outlander 800 H.O. EFI 06 12x7 4X137
50DS 07
90DS 07
400 Outlander HOXXT 07-08 12x7 4X137
400 Outlander HO Max 4x4 07-08 12x7 4X137
DS450 X 08-09 10x5, 9x9 4X144, 4X110
500 Outlander HO EFIXMax 07-09 12x7 4X137
500 Outlander HO EFI XT, Max XT 07-09 12x7 4X137
650 Outlander HO MaxXEFI 07-08 12x7 4X137
650 HO EFI 4x4XXT 07-08 12x7 4X137
650 Outlander HO Max 4x4 07-08 12x7 4X137
650X DS 07 10x5, 9x9 4X143
800 Renegade 07-09 12x7 4X137
800 Outlander HO EFIXXT 07-08 12x7 4X137
800 Outlander HO Max All 07-08 12x7 4X137




Honda ATV Steekmaten op type:

Type/Bouwjaar/Velgmaat(V/A) Steekmaat(V/A)

ATC70 82-85 7x6 4X110, 3X100
TRX70 Fourtrax 86-87 7x6 4X110, 3X100
ATC90 71-78 8x8 3X100
TRX90 Fourtrax 93-09 8x5.5, 8x6.5 4X85
TRX90 Sportrax 02-05 8x5.5, 8x6.5 4X85
TRX90 06 8x5.5, 8x6.5 4X85
TRX90 EX 07-09 8x5.5, 8x6.5 4X85
ATC110 79-81 8x8(R) 3X100
ATC110 82-83 8x8(R) 4X130
ATC110 84-85 8x8(R) 4X130
ATC125M 84-85 8x8(R) 4X130
ATC125M 86-87 8x8(R) 4X130
TRX125 Fourtrax 84-86
TRX125 Fourtrax 87-88
ATC185 80 9x9(R) 4X130
ATC185S 81 8x8(R) 3X100
ATC185S 82-83 8x8(R) 4X130
ATC200 81 9x9(R) 4X150
ATC200 82-83 9x9(R) 4X150
ATC200E Big Red 82-83 9x9(R) 4X150
ATC200E Big Red 84 9x9(R) 4X150
ATC200M 84-85 9x9(R) 4X150
ATC200S 84-86 8x8(R) 4X130
ATC200X 83-85 8x8(R) 4X110
ATC200X 86-87 9x9(R) 4X110
TRX200 Fourtrax 84 9x9(R) 4X150
TRX200SX Fourtrax 86-88 8x8(R) 4X110
TRX 200 Fourtrax 200 90-91 10x5, 8x8 4X110
TRX200XD Fourtrax Type II 91-97
ATC250R 81 8x8(R) 3X100
ATC250R 82 8x8(R) 4X130
ATC250R 83 8x8(R) 4X110
ATC250R 84 8x8(R) 4X110
ATC250R 85-86 9x9(R) 4X110
ATC250ES Big Red 85-87 9x9(R) 4X110
ATC250SX 85-87 8x9(R) 4X110
FL250 Odyssey 77-80 8x5, 8x8 3X100
FL250 Odyssey 81 8x5, 8x8 3X100
FL250 Odyssey 82-84 8x8(R) 4X130
TRX250 Fourtrax 250 85-87 10x5, 9x9 4X110
TRX250 ReconXES 97-09 11x7, 9x9 4X110
TRX250R 86-89 10x5, 9x9 4X144, 4X110
TRX250R Fourtrax 88-89 10x5, 9x9 4X144, 4X110
TRX250X Fourtrax 87-88, 91-93 10x5, 9x9 4X110
TRX250EX 01-09 10x5, 9x9 4X144, 4X110
TRX300 Fourtrax 88-91 11x7, 9x9 4X110
TRX300 Fourtrax 92-00 11x7(F) 4X110
TRX300EX Sportrax 01-09 10x5, 9x9 4X144, 4X110
TRX300EX Fourtrax 93-00 10x5, 9x9 4X144, 4X110
TRX300FW 4x4 88 11x7 4X110
TRX300FW 4x4 88, 90-00 11x7 4X110
ATC350X 85-86
FL350R Odyssey 85 10x5(F) 4X110
TRX350 4x4 86-89 11x7 4X110
TRX350 Rancher SXES 2x4 00-09 12x7, 10x8 4X110
TRX350 Rancher SXES 4x4 00-09 12x7, 11x7 4X110
TRX350FM 00-02 12x7, 11x7 4X110
TRX350TEXTM Rancher 00-02 12x7, 10x8 4X110
TRX400EX 06-09 10x5, 9x9 4X144, 4X110
TRX400FW Foreman 4x4 95-03 12x7, 11x7 4X110
TRX400FA Fourtrax Rancher AT 04-07 12x7, 11x7 4X110
TRX400 RancherXGPScape 04-07 12x7, 11x7 4X110
TRX420 TMXTE Fourtrax Rancher SXES 07-09 12x7, 11x7 4X110
TRX420FMXFE Fourtrax Rancher 4x4 SXES 07-09 12x7, 11x7 4X110
TRX450SXES Fourtrax Foreman SXES 98-01 12x7 4X110
TRX450FMXFE Fourtrax Foreman SXES 02-04 12x7 4X110
TRX450ER, TRX450R Kick Start 04-05 10x5, 9x9 4X144, 4X110
TRX450ER, TRX450R, Kick Start 06-07 10x5, 9x9 4X144, 4X110
TRX450ER, TRX450R, Kick Start 08-09 10x5, 9x9 4X144, 4X110
TRX450ER. TRX450R, Electric Start 06-07 10x5, 9x9 4X144, 4X110
TRX450ER, TRX450R, Electric Start 08-09 10x5, 9x9 4X144, 4X110
TRX500 RubiconXGPScape 01-09 12x7 4X110
TRX500FGA Fourtrax Rubicon GPScape 04-09 12x7 4X110
TRX500FPM Fourtrax Foreman 4x4 08-09 12x7 4X110
TRX500FPE Fourtrax Foreman 4x4 ES 07-09 12x7 4X110
TRX500TM Fourtrax Foreman 2x4 05-06 12x7 4X110
TRX500FM Fourtrax Foreman 4x4 05-09 12x7 4X110
TRX500FE Fourtrax Foreman 4x4 ES 05-09 12x7 4X110
TRX650FGA Fourtrax Rincon 04-05 12x7 4X110
TRX650FA Rincon GPScape 03-05 12x7 4X110
TRX680FGA RinconXGPScape 06-09 12x7 4X110
TRX680FA Fourtrax Rincon 06-09 12x7 4X110
TRX700XX 08-09 10x5, 11x7 4X144
BIG RED MUV 4wd 09 12x7 4X110




Kawasaki ATV Steekmaten op type:

Type/Bouwjaar/Velgmaat(V/A) Steekmaat(V/A)

KSF50AXKFX50 03-06
KSF50BXKFX50 07-09
KSF80AXKFX80 03-06
KSF90AXKFX90 07-09 8x5.5, 8x7 4X110
KLF110A Mojave 110 87-88 8x5.5, 8x7 4X110
KLF110B Mojave 110E 87-88 8x8(R) 4X4
KLT110AXKLT110 3 Wheel 84 8x8(R) 4X4
KLT110AXKLT110 3 Wheel 85 8x8(R) 4X4
KLT110AXKLT110 86 8x8(R) 4X4
KLT160AXKLT160 85 8x8(R) 4X4
KLF185AXKLF185 Bayou 85-88 8x8(R) 4X4
KLT185AXKLT185 86-87 8x8(R) 4X4
KLT200 3 Wheel 81-82 8x8(R) 4X4
KLT200 3 Wheel 83 8x8(R) 4X4
KLT200C Duckster 83 8x8(R) 4X4
KLT200C 3 Wheel 83-84 8x8(R) 4X4
KLF220 Bayou 88-99 9x6, 10x8 4X137
KLF220 Bayou 00-02 9x6, 10x8 4X137
KLF250 Bayou 03-09 9x6, 10x8 4X137
KLT250A 3 Wheel 82-83 9x9 (R) 4X4
KLT250C Prairie 83 9x9 (R) 4X4
KLT250C Prairie 84-85 8x8 (R) 4X4
KLT250P Police 84 8x8 (R) 4X4
KSFXKFX250 Mojave 87-99 10x5, 10x8 4X156
KSFXKFX250 Mojave 00-03 10x5, 10x8 4X156
KSF250AXKFX250 Mojave 04 10x5, 10x8 4X156
KXF250 Tecate 87-88 10x8 (R) 4X156
KXT250 Tecate 84 10x8 (R) 4X4
KXT250 Tecate 85-87 10x8 (R) 4X156
KEF300 Lakota 300 95-99 10x5, 10x8 4X156
KEF300A Lakota 300 00 10x5, 10x8 4X156
KEF300-B1 Lakota Sport 01-03 10x5, 10x8 4X156
KLF300A Bayou 86-87 10x6, 10x8 4X137
KLF300B Bayou 88 10x6, 10x8 4X137
KLF300B Bayou 89-99 10x6, 10x8 4X137
KLF300B Bayou 2x4 00-04 10x6, 10x8 4X137
KLF300C Bayou 4x4 89-99 11x6, 11x7 4X137
KLF300C Bayou 4x4 00-04 11x6, 11x7 4X137
KVF300B Prairie 2x4 99 12x7, 10x8 4X137
KVF300B Prairie 2x4 00-02 12x7, 10x8 4X137
KVF300A Prairie 4x4 99 12x7, 10x8 4X137
KVF300A Prairie 4x4 00-02 12x7, 10x8 4X137
KVF360B Prairie 2x4X4x4 03-09 12x7, 10x8 4X137
KLF400B Bayou 4x4 93-99 11x6, 11x7 4X137
KSF400AXKFX400 03-06 10x5, 9x9 4X144, 4X110
KSF400AXKVF400 Prairie 03-06 9x9(R) 4X110
KVF400B Prairie 2x4 98 12x7, 10x8 4X137
KVF400D Prairie 2x4 99 12x7, 10x8 4X137
KVF400D Prairie 2x4 00-02 12x7, 10x8 4X137
KVF400A Prairie 4x4 97-98 12x7, 10x8 4X137
KVF400C Prairie 4x4 99 12x7, 10x8 4X137
KSF450BXKFX450R 08-09 9x9 (R) 4X144, 4X110
KVF650AXB Prairie 4x4 02-03 12x7 4X137
KVF650DXE Brute Force 650 4x4 05-09 12x7 4X137
KVF650FXGXH Brute Force 4x4 i 06-09 12x7 4X110
KVF700AXBXD Prairie 4x4 04-06 12x7 4X137
KSV700AXBXC KFX700 V-Force 04-09 10x5, 10x8 4X144, 4X137
KVF750A-F Brute Force 750 4x4 i 05-09 12x7 4X110
KAF300A Mule 500 91 10x7, 10x8 4X137
KAF300B Mule 500 93, 95 10x7, 10x8 4X137
KAF300D Mule 520 00-01
KAF300C Mule 550 97-01, 03-04 10x7, 10x8 4X137
KAF400B Mule 600 05-08 10x7, 10x8 4X137
KAF400AXC Mule 610 4x4 05-08
KAF450B Mule 1000 88 10x8 4X137
KAF540C Mule 2010 90 10x8 4X137
KAF540D Mule 2020 90
KAF540E Mule 2030 91
KAF620C Mule 2500 94-95, 97-00 10x8 4X137-12mm
KAF620A Mule 2510 4x4 93, 95, 97-00 10x8 4X137-12mm
KAF620B Mule 2520 Turf 93, 95, 97-00
KAF620G Mule 3000 01-08 10x8 4X137-12mm
KAF620EXH Mule 3010 4x4 01-08 10x8 4X137-12mm
KAF620F Mule 3020 Turf 01-03
KAF620JXK Mule 3010 Trans 4x4 05-08 10x8 4X137-12mm
KAF950A Mule 2510 Diesel 00-02 10x8 4X137-12mm
KAF950BXD Mule 3010 Diesel 4x4 03-08 10x8 4X137-12mm
KAF950CXE Mule 3010 Trans 4x4 Diesel 07-08 10x8 4X137-12mm
KRF750A-F TERYX 750 4x4 08-09 12x7 4X137-12mm




Polaris ATV Steekmaten op type:

Type/Bouwjaar/Velgmaat(V/A) Steekmaat(V/A)

50 Outlaw 08-09
50 Predator 04
50 Predator(if built before 8X1X04) 05
50 Predator (if built after 8X1X04 05-06
50 Predator 07
50 Scrambler 01-02
50 Scrambler 03
90 Outlaw 07-09
90 Predator 04-06
90 Scrambler 01
90X90X Scrambler 02
90 Scrambler 03
90 Sportsman 01-06
90 Sportsman 07-09
200 Phoenix 05-09
200 Sawtooth 06-07
250X Cyclone 87 10x5, 10x8 4X156, 4X4
250 Scrambler 85-86 10x5, 10x8 4X156, 4X4
250 Trail Blazer 91-93 10x5, 10x8 4X156, 4X4
250 Trail Blazer 94 10x5, 10x8 4X156, 4X4
250 Trail Blazer 95 10x5, 10x8 4X156, 4X4
250 Trail Blazer ES 96 10x5, 10x8 4X156, 4X4
250 Trail Blazer 97-98 10x5, 10x8 4X156, 4X4
250 Trail Blazer 99-00 10x5, 10x8 4X156, 4X4
250 Trail Blazer (if built before7X15X00) 01 10x5, 10x8 4X156, 4X4
250 Trail Blazer (if built after 7X15X00) 01 10x5, 10x8 4X156, 4X4
250 Trail Boss 2x4 89-93 10x5, 10x8 4X156, 4X4
250 Trail Boss 4x4 89-93 10x5, 10x8 4X156, 4X4
250 TrailBoss 90-93 10x5, 10x8 4X156, 4X4
250 Trail Boss 94 10x5, 10x8 4X156, 4X4
250 Trail Boss 95 10x5, 10x8 4X156, 4X4
250 Trail Boss 96-99 10x5, 10x8 4X156, 4X4
250 Trail Boss 2x4 85-87 10x5, 10x8 4X156, 4X4
250 Trail Boss 4x4 87-88 10x5, 10x8 4X156, 4X4
250 Xplorer 4x4 00-01 10x5, 10x8 4X156, 4X4
300 Big Boss 6x6 94 10x5, 10x8 4X156, 4X4
300 Hawkeye 2x4X4x4 06-07 10x5, 10x8 4X156, 4X4
300 2x4 94-95 10x5, 10x8 4X156, 4X4
300 Xplorer 4x4 97-99 10x5, 10x8 4X156, 4X4
300 Xpress 96-99 10x5, 10x8 4X156, 4X4
325 Magnum 00-02 12x7, 10x8 4X156, 4X4
325 Trail Boss 00 10x5, 10x8 4X156, 4X4
325 Trail Boss SE 01-02 10x5, 10x8 4X156, 4X4
325 Xpedition 00-02 12x7, 10x8 4X156, 4X4
330 Magnum 2x4 03-05 12x7 4X156
330 Magnum 4x4 03-06 12x7 4X156
330 Sportsman ATP 04-05 12x7 4X156
330 Trail Blazer 08-09 10x5, 10x8 4X156, 4X4
330 Trail Boss 03-09 10x5, 10x8 4X156, 4X4
335 Sportsman 99-00 10x5, 10x8 4X156, 4X4
350L Trail Boss 2x4 90-93 10x5, 10x8 4X156, 4X4
350L Trail Boss 4x4 90-93 12x7, 10x8 4X156, 4X4
350L Big Boss 6x6 93 12x7, 10x8 4X156, 4X4
400L 2x4 94-95 10x5, 10x8 4X156, 4X4
400L 4x4 94 12x7, 10x8 4X156, 4X4
400L BigBoss 6x6 94-97 12x7, 10x8 4X156, 4X4
400L Sport 94 10x5, 10x8 4X156, 4X4
400L Sportsman 4x4 93-94 12x7, 10x8 4X156, 4X4
400 Sportsman 4x4 01-02 12x7, 10x8 4X156, 4X4
400 Sportsman 4x4 03 12x7, 10x8 4X156, 4X4
400 Sportsman 4x4 04-05 12x7, 10x8 4X156, 4X4
400L 2x4 94-95 10x5, 10x8 4X156, 4X4
400L Scrambler 2x4 00-02 10x5, 10x8 4X156, 4X4
400L Scrambler 4x4 95-97 10x5, 10x8 4X156, 4X4
400L Xplorer 95-96 12x7, 10x8 4X156, 4X4
400L Xplorer 4x4 97-98 12x7, 10x8 4X156, 4X4
400L Xplorer 4x4 99-02 12x7, 10x8 4X156, 4X4
400L Big Boss 6x6 94-97 12x7, 10x8 4X156, 4X4
400L Sport 95-98 10x5, 10x8 4X156, 4X4
400L Xpress 96-97 10x5, 10x8 4X156, 4X4
400 Sportsman 03-05 12x7, 10x8 4X156, 4X4
400 Trail Blazer 03 10x5, 10x8 4X156, 4X4
425L Magnum2x4 95 10x5, 10x8 4X156, 4X4
425L Magnum2x4 96-98 10x5, 10x8 4X156, 4X4
425L Magnum4x4 95 12x7, 10x8 4X156, 4X4
425L Magnum4x4 96-98 12x7, 10x8 4X156, 4X4
425L Magnum6x6 96-97 12x7, 10x8 4X156, 4X4
425 Xpedition 00-01 12x7, 10x8 4X156, 4X4
425 Xpedition 02 12x7 4X156
450 Outlaw MXR 08-09
450 Sportsman 4X4 06-07 12x7, 10x8 4X156, 4X4
450 Sportsman AT 4x4 06 12x7 4X156
460 Diesel 4x4 99-01 12x7, 10x8 4X156, 4X4
500 Magnum 99-02 12x7, 10x8 4X156, 4X4
500 Outlaw 06-07 10x5, 9x9 4X156, 4X110
500 Predator 03 10x5, 10x8 4X156
500 Predator 04 10x5, 10x8 4X156, 4X110
500 Predator 05-07 10x5, 10x8 4X156, 4X110
500 PredatorXLE 04 10x5, 10x8 4X156, 4X110
500 PredatorXLE 05-07 10x5, 10x8 4X156, 4X110
500 Scrambler 4x4 97-98 10x5, 10x8 4X156, 4X4
500 Scrambler 4x4 99-09 10x5, 10x8 4X156, 4X4
500 Scrambler 2x4 01-02 10x5, 10x8 4X156, 4X4
500 Sportsman 4x4 96-02 12x7, 10x8 4X156, 4X4
500 Sportsman HO 03-06, 08 12x7, 10x8 4X156, 4X4
500 Sportsman ATP 04-05 12x7 4X156
500 Sportsman EFI 06 12x7 4X156
500 Sportsman EFI 07-08 12x7 4X156
500 Sportsman 6x6 01-08 12x7, 10x8 4X156, 4X4
500 Sportsman Touring EFI 08-09 12x7 4X156
500 Sportsman X2 06-08 12x7 4X156
525 OutlawXIRS 07-09 10x5, 9x9 4X156, 4X110
525 Outlaw S 08-09 10x5, 9x9 4X156, 4X110
600 Sportsman (built before 10X8X04) 03-04 12x7 4X156
600 Sportsman (built after 10X8X04) 04-05 12x7 4X156
700 Sportsman 02-04 12x7 4X156
700 Sportsman 05-06 12x7 4X156
700 Sportsman EFI 05-07 12x7 4X156
800 Sportsman EFI 05-07 12x7 4X156
800 Sportsman EFI HO 08-09 12x7 4X156
800 Sportsman Touring EFI 08-09 12x7 4X156
800 Sportsman X2 07-09 12x7 4X156
425 Ranger 2x4 01-05 12x7 4X156
500 Ranger 2x4 06-08 12x7 4X156
500 Ranger 4x4 05 12x7 4X156
500 Ranger 4x4 EFI 06-09 12x7 4X156
500 Ranger 6x6 99-00 12x7, 10x8 4X156, 4X4
500 Ranger 6x6 01-05 12x7 4X156




Suzuki ATV Steekmaten op type:

Type/Bouwjaar/Velgmaat(V/A) Steekmaat(V/A)

ALT50 Trail Buddy 83-84 6x6 3X90
LT50 Quad Runner 84-87 6x6 3X90
LT-A50 QuadMaster 02-05 6x6 3X90
LT-Z50 Quadsport 06-09 6x6 3X90
LT80J Quadsport 87-88 8x6 3X120
LT80 Quadsport 89-95 8x6 3X120
LT80 Quadsport 96-06 8x6 3X120
LT-Z90 Quadsport 07-09 8x6 3X120
ALT125 3 Wheel 83-86 8x8(R) 3X100, 4X130
LT125 Quadrunner 83-87 8x6, 8x8 4X112
LT160E Quadrunner 89 8x6, 8x8 4X112
LT160E Quadrunner 91-97 8x6, 8x8 4X112
LT160E Quadrunner 98-01 8x6, 8x8 4X112
LT160 Quadrunner 03-04 8x6, 8x8 4X112
LTF160 91-96 8x6, 8x8 4X112
LTF160 97-01 8x6, 8x8 4X112
ALT185 3 Wheel 85 8x8(R) 4X130
LT185 Quadrunner 84-87 8x6, 8x8 4X112
LT230GE Quadrunner 85-86 9x6, 8x8 4X130
LT230E Quadrunner 87 10x5, 9x9 4X166, 4X130
LT230EJ Quadrunner 88-93 10x5, 9x9 4X166, 4X130
LT230E Quadrunner 89 9x6, 9x9 4X166, 4X130
LT230E Quadrunner 91-93 10x5, 9x9 4X166, 4X130
LT230S Quadsport 85-86 10x5, 9x9 4X166, 4X130
LT230S Quadsport 87-88 10x5, 9x9 4X166, 4X130
LT250EF Quadrunner 85 9x6, 9x9 4X130
LT250EF Quadrunner 86 9x6, 9x9 4X130
LT250R Quadracer 85-86 10x5, 9x9 4X166, 4X130
LT250R Quadracer 87
LT250R Quadracer 88-92
LTF250 Quadrunner 88-97 10x5, 10x8 4X140
LTF250 Quadrunner 98-02 10x5, 10x8 4X140
LTF250 Ozark 03-09 11x7, 9x9 4X110
LT250S Quadsport 89
LT250S Quadsport 90
LT250S Quadsport 04-09 10x5, 9x9 4X144, 4X110
LT4WD Quadrunner 87-96
LT4WD Quadrunner 97
LT4WD Quadrunner 98-02
LT300E Quadrunner 87-89
LTF300F King Quad 99-02
LTF300 King Quad 4x4 91-97 11x6, 12x7 4X140, 5X160
LTF300 King Quad 4x4 98 11x6, 12x7 4X140, 5X160
LTF4WD 92-96 11x6, 12x7 4X140, 5X160
LT-A400 Eiger Auto 2x4 02-04, 06-07 12x7 4X110
LT-A400F Eiger Auto 4x4 02-07 12x7 4X110
LTA400F King Quad 400AS 4x4 08-09 12x7 4X110
LTF400 Eiger 400 2x4 02-07 12x7 4X110
LTF400F Eiger 400 4x4 02-07 12x7 4X110
LTA400F King Quad 400FS 4x4 08-09 12x7 4X110
LT-Z400XZ Quadsport 03-09
LTA450X King Quad 4x4X450 Axi 4x4 07-09 12x7 4X110
LT-R450 Quadracer 06-09 10x5, 8x8 4X144, 4X110
LT500R Quadracer 87 10x5, 10x8 4X166, 5X130
LT500R Quadracer 88-90 10x5, 10x8 4X166, 5X130
LT500F Quad Master 4x4 00-01
LTF-A500F Vinson Auto 4WD 02-03 12x7 4X110
LTF-A500F Vinson Auto 4WD 04-07 12x7 4X110
LTF500F Quad Runner 4x4 98-02 12x7, 12x8 4X90
LTF500F Vinson 500 4x4 03 12x7 4X110
LTF500F Vinson 500 4x4 04-07 12x7 4X110
LTV700F Twin Peaks 4x4 04-05 12x7 4X137
LTA700X King Quad 700 4x4 05-07 12x7 4X110
LTA750X King Quad Axi 4x4 08-09 12x7 4X110
QUV620F Q.U.V. 4x4 05




Yamaha ATV Steekmaten op type:

Type/Bouwjaar/Velgmaat(V/A) Steekmaat(V/A)

YFM50 Raptor 04-08
YFM80 Grizzly 05-08 7x6 3X70, 4X88
YFM80 Moto 4 85-88
YFM80 Badger 92-01
YFM80 Raptor 02-03
YFM80 Raptor 04-08
YFM100 Champ 87-91
YFA125 Breeze 89-03 8x7, 8x8 4X85
YFA125 Breeze 04 8x7, 8x8 4X85
YFA125 Breeze 03-04 8x7, 8x8 4X85
YFM125GXGH Grizzly 125 Auto 04-09
YT125 Tri-Moto 80-81 8x8 3X100
YT125 Tri-Moto 82-85 8x8 3X100
YT175 Tri-Moto 82-84 8x8 3X100
YFM200DX Moto-4 85-87 10x5, 8x8 4X156, 4X100
YFM200DX Moto-4 88-89 10x5, 8x8 4X156, 4X100
YTM200 Tri-Moto 83-85
YTM200E Yamahauler 83-85
YFS200 Blaster 88-00
YFS200XSE Blaster 01-06
YFM225 Moto-4 85-92 10x5, 9x9 4X156, 4X125
YTM225 Tri-Moto 83-86 8x8 (R) 4X100
YFU1 Pro Hauler 237 89
YFU1T Pro Hauler Turf 237 89
YFB250 Bear Tracker 99-04 10x5, 10x8 4X110
YFM250 Big Bear 07-09 10x5, 10x8 4X110
YFM250 Bruin 05-06 10x5, 10x8 4X110
YFM250RXRSPXXRSPX2 Raptor 250 08 10x5, 9x9 4X156, 4X115
YTZ250 Tri Z 85 8x8 (R) 4X100
YTZ250 Tri Z 86 9x8 (R) 4X100
YFB250XU Timberwolf 2x4 92-98 10x5 (F) 4X156, 4X115
YFB250FW Timberwolf 4x4 94-00 10x5, 10x8 4X110
YFM250 Moto 4 89-91 10x6, 9x9 4X110
YFZ350 Banshee 87-88 10x5, 9x9 4X156, 4X115
YFZ350 Banshee 89 10x5, 10x8 4X156
YFZ350 Banshee 90 10x5, 10x8 4X156
YFZ350 Banshee 91-02 10x5, 9x9 4X156, 4X115
YFZ350 Banshee 03-06
YFM350 Bruin 2x4X4x4 04-06 12x7 4X110
YFM350 Grizzly Auto 2X4x4 07-09 12x7 4X110
YFM350ER 87-88 10x5, 9x9 4X156, 4X125
YFM350ER 89-95 10x5, 9x9 4X110, 4X125
YFM350 Raptor 04-09 10x5, 9x9 4X156, 4X115
YFP350 Terra Pro 87-88
YFM350X Warrior 86-87
YFM350X Warrior 88
YFM350X Warrior 90-91 10x5, 9x9 4X156, 4X115
YRM350X Warrior 92-96 10x5, 9x9 4X156, 4X115
YFM350X Warrior 97-04 10x5, 9x9 4X156, 4X115
YFM350FW 4WD 87-02 12x7 4X110
YFM350FX Wolverine 95-01 12x7 4X110
YFM350FX Wolverine 02-05 12x7 4X110
YFM350 2x4 97-98 12x7, 9x9 4X110
YFU1W Prohauler 89
YFM400 Big Bear 00-07 12x7 4X110
YFM400 Grizzly Auto 07-08 12x7 4X110
YFM400FW Kodiak 93-95 12x7 4X110
YFM400FW Kodiak 96-02 12x7 4X110
YFM400FA Kodiak Auto 03-06 12x7 4X110
YFM450 Grizzly Auto 07-09 12x7 4X110
YFM450FA Kodiak Auto 03-06 12x7 4X110
450 Rhino 07 12x7 4X110
YFM450 WolverineXSE 07 12x7 4X110
YFZ450XBalanceXSE 04-07 10x5, 9x9 4X156, 4X115
YFM600 Grizzly 98-01 12x7 4X110
YFM660 Grizzly 02-07 12x7 4X110
YFM660 Raptor 01-05 10x5, 9x9 4X156, 4X115
660 Rhino 06-07 12x7 4X110
YFM700 Grizzly All 07 12x7 4X110
700 Rhino 08-10 12x7 4X110
YFM700 Raptor.2XGYTRXSE 06-07 10x5, 9x9 4X156, 4X115
